Instruction
GRAY CODE CONVERSION
GRAY CODE TO BINARY
CONVERT
DOUBLE GRAY CODE TO
BINARY CONVERT
DOUBLE GRAY CODE TO
BINARY CONVERT
DOUBLE BINARY TO GRAY
CODE CONVERT
FOUR-DIGIT NUMBER TO
ASCII
EIGHT-DIGIT NUMBER TO
ASCII
SIXTEEN-DIGIT NUMBER
TO ASCII
ASCII TO FOUR-DIGIT NUM-
BER
ASCII TO EIGHT-DIGIT NUM-
BER
ASCII TO SIXTEEN-DIGIT
NUMBER
4-1-11 Logic Instructions
Instruction
LOGICAL AND
DOUBLE LOGICAL AND
LOGICAL OR
DOUBLE LOGICAL OR
EXCLUSIVE OR
DOUBLE EXCLUSIVE OR
EXCLUSIVE NOR
DOUBLE EXCLUSIVE NOR
COMPLEMENT
DOUBLE COMPLEMENT
CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
Mnemonic Length
(steps)
GRY 4
GRAY_BIN 3
GRAY_BINL 3 to 4
BIN_GRAY 3
BIN_GRAYL 3 to 4
STR4 3
STR8 3 to 4
STR16 3
NUM4 3 to 4
NUM8 3
NUM16 3
Mnemonic Length
(steps)
ANDW 4
ANDL 4 to 6
ORW 4
ORWL 4 to 6
XORW 4
XORL 4 to 6
XNRW 4
XNRL 4 to 6
COM 2
COML 2
ON execution time ( s)
CJ2H CJ2M CPU@@
CPU6@(-EIP)
26.5 49.1
27.6 51.1
30.9 57.2
35.3 66.0
36.3 68.0
39.6 74.0
0.1 0.3
0.1 0.4
0.1 0.3
0.1 0.4
8.4 14.2
10.2 16.4
15.8 28.2
10.5 18.5
14.8 27.1
27.4 52.0
ON execution time ( s)
CJ2H CJ2M CPU@@
CPU6@(-EIP)
0.14 0.340
0.26 0.640
0.18 0.340
0.26 0.640
0.18 0.340
0.26 0.640
0.18 0.340
0.26 0.640
0.18 0.240
0.32 0.440
Conditions
8-bit binary
8-bit BCD
8-bit angle
15-bit binary
15-bit BCD
15-bit angle
---
---
---
---
---
---
4
---
---
---
---
Conditions
---
---
---
---
---
---
---
---
---
---
1155
