3. Instructions
Example Programming
CADD
When CIO 0.00 turns ON in the following example, the calendar data in D100 through D102 (year,
month, day, hour, minutes, seconds) is added to the time data in D200 and D201 (hours, minutes,
seconds) and the result is output to D300 through D302.
0.00
C
T
R
CSUB
When CIO 0.00 turns ON in the following example, the time data in D200 and D201 (hours, minutes,
seconds) is subtracted from the calendar data in D100 through D102 (year, month, day, hour, minutes,
seconds) and the result is output to D300 through D302.
0.00
C
T
R
1008
D100
C:
D100
D200
D101
D102
D300
T:
D200
D201
R:
D300
D301
D302
C:
D100
D101
D100
D102
D200
D300
T:
D200
D201
R:
D300
D301
D302
18:30:20
99 12 10 December, 1999
10 minutes, 15 seconds
06 00
600 hours
18:40:35
04 18
4 January, 2000
00 01
18:30:20
10 July, 1998
50 hours, 10 minutes, 15 seconds
16:20:05
8 July, 1998
