Board Specifications
Dimensions
PCB
Height: 7.517 inches (19.09 cm)
Length: 9.470 inches (24.05 cm)
Thickness: 64.5 mil ±5 mil (1.64 mm ±0.13 mm)
Evaluation Board
Thickness fully assembled: 1.976 inches (5.017 cm)
Fully assembled, from table to bottom of PCB: 0.673 inches (1.710 cm)
✎
Note:
A 3D model of this board is not available.
See the
VEK280 Evaluation Kit
Environmental
✎
Note:
The operating temperature range is not fully tested across the specified
temperature range. It is for general guidelines only. Customers should use the
VEK280 evaluation board for evaluation purposes only in a normal lab environment
and should not operate beyond room temperature.
Temperature
Operating: 0°C to +45°C
Storage: –25°C to +60°C
Humidity
5% to 95% non-condensing
Operating Voltage
+12 V
DC
Mechanical
The VEK280 evaluation board includes a mechanical stiffener to help ensure
success with the board under normal lab conditions and use. While it is
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Unofficial Document
website for the XDC listing and board schematics.
8/78
