Callout No. Ref. Des.
12 U33
13 U233
14 J392,
J393
17 J376
18 J390,
J391
19 J307
20 J51
21 Various
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Feature
SoC SD 3.0 level
translator circuit
I2C bus switches
I2C bus expander
CAN bus
connectors
zSFP+ connector
HDMI™ TX and
HDMI RX
connectors
GEM0 SGMII
Ethernet PHY,
0x01, RJ45 w/mag
FMCP1
Adaptive SoC
power
management
Unofficial Document
Notes
Texas Instruments
TCA9548APWR
IC switch bus 1-In 8-Outs
I2C 400 kHz
Bottom of board
Texas Instruments
TCA6416APWR
IC exp. GPIO 16-bit I2C 400
kHz
Bottom of board
Phoenix 1935174
Conn Term Blk RA 3 Pos
1x3 5 mm P 17.5A 250V
Green TH 14-26AWG Screw
Clamp
Molex 1703820001
zSFP+ connector and cage
Molex 2086581061
Conn Rcpt HDMI 2.1 RA
Halo HFJ11-1G01E-L12RL
RJ-45 Gigabit connector
Samtec ASP-184329-01
560 pos. connector 14x40
1.27 mm
Infineon regulators
Schematic Page
39
39
41
29
44-45
36
30-34
51-56
