Cooling Fan Connector
[Figure
1, callout 35]
The VEK280 cooling fan connector is shown in the following figure. The VEK280
uses the system controller to autonomously control the fan speed by controlling the
pulse width modulation (PWM) signal to the fan. The fan rotates slowly
(acoustically quiet) when the Versal device's U1 is cool and rotates faster as the
device heats up (acoustically noisy).
The VEK280 board provides a fan controller bypass header J347 and J348 to
permit control by the Versal device. See the
more details.
Figure: 12V Fan Header
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Unofficial Document
Default Jumper and Switch Settings
for
65/78
