Callout Number Ref. Des.
17 SW4,
SW5
18 SW6
19 SW12
20 SW13
21 SW14
22 SW15
23 SW16
Versal Device Configuration
The "Platform Boot, Control, and Status" section of the Versal Adaptive SoC
Technical Reference Manual (AM011) describes the Versal XCVE2802 device boot
process. The VEK280 board supports a subset of the modes documented in the
technical reference manual via onboard boot options. The mode DIP switch SW1
configuration option settings are listed in the following table.
Table: Mode Switch SW1 Configuration Option Settings
Boot Mode
JTAG
OSPI
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Function
User pushbutton inputs
✎
Note: Pushbutton switch
default = open = logic low (not
pressed).
User GPIO DIP
Switch OFF = 0 = low; ON = 1 =
high
System controller power-on reset
(SYSCTL_POR_B)
Main power
User USB reset
User GEM reset
System controller FWUEN
pushbutton
(SYSCTLR_MIO12_FWUEN_C2M_B)
See BEAM wiki for more
information
Mode Pins [0:3]
1,3
0000
0001
Unofficial Document
Default
Open
OFF, OFF,
OFF, OFF
Open
Open
Open
Open
2
Mode SW1 [1:4]
ON, ON, ON, ON
ON, ON, ON, OFF
Schematic Page
48
48
77
OFF 50
37
36
76
2
