Bank MIO #
18
19
20
21
22
23
24
25
501 26
27
28
29
30
31
32
33
34
35
36
37
38
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Device
PMC_MIO18_USB_CLKOUT O
PMC_MIO19_USB_DAT4 I/O
PMC_MIO20_USB_DAT5 I/O
PMC_MIO21_USB_DAT6 I/O
PMC_MIO22_USB_DAT7 I/O
PMC_MIO23_USB_DIR
PMC_MIO24_USB_STP
PMC_MIO25_USB_NXT
SD PMC_MIO26_SD_CLK
PMC_MIO27_SD_DIR1
PMC_MIO28_SD_DET
PMC_MIO29_SD_CMD
PMC_MIO30_SD_DAT0
PMC_MIO31_SD_DAT1
PMC_MIO32_SD_DAT2
PMC_MIO33_SD_DAT3
PMC_MIO34_SD_SEL
PMC_MIO35_SD_DIR_CMD O
PMC_MIO36_SD_DIR0
Factory/CANFD0 PMC_MIO37_COMBINED I/O
See CAN
Interface
CANFD0 PMC_MIO38_CAN0_nSTBO
Unofficial Document
Signal I/O
I/O
O
I/O
O
O
I
I/O
I/O
I/O
I/O
I/O
I/O
O
Notes
Selectable J406,
Factory/CANFD0_INH_B
Standby mode
control input
