System Controller

[Figure 1, callout 44]
The VEK280 board includes an onboard system controller. The system controller
hosts a website that allows for various controls over aspects of the evaluation
board. This web-based interface enables the query and control of select
programmable features such as clocks, FMC functionality, and power system
parameters. Users should not change the default system controller image as that
could potentially cause damage to the board if proper procedures are not followed.
If this image needs to be updated and for more information on the system
controller web interface, see the
The web application is shown in the following figure.
Figure: System Controller Web User Interface
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Unofficial Document
Versal Evaluation Board System Controller Wiki.
