AMD XILINX VEK280 User Manual page 15

3/20/24, 12:51 PM
Callout No. Ref. Des.
31 J325
32 Various
33 J16
34 JP1,
JP2
35 J233
36 U299
37 J374
38 U297
39 DS1
40 DS2
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Feature
PMBus 3-pin
header
Power good LEDs
(see Power and
Status LEDs for
more details)
Power connector,
2x3, for AC-DC
power adapter
Power connector,
2x4, for ATX PCIe
power
Fan header (keyed
4-pin)
MGT and system
clock generators
RC21008A_GTCLK
header
Adaptive SoC U1
OSPI
Done LED (Active-
High-Z and pulled
High)
Error out LED
(Active-High-Z and
pulled High)
Unofficial Document
Notes
Sullins PBC03SAAN
Conn. hdr. vert. 3 pos. 1x3
2.54 mm
Various; see the Bill of
Materials
Molex 0039301060
Conn. ddr. RA 6 pos. 2x3
4.2 mm
Astron 6652208-T0003T-H
Conn. hdr. male RA 8 pos.
2x4 4.2 mm
Molex 0470533000
Keyed fan header 4 pos.
0.100" vert.
Renesas
RC21008A065GND#BB0
Molex 0878321820
Micron
MT35XU02GCBA1G12-0SIT
IC flash Xccela 2 Gb SPI
200 MHz 1.8V
Lumex SML-LX0603GW-TR
LED green
Lumex SML-LX0603IW-TR
LED red
Schematic Page
55
72
50
50
50
93
93
28
12
12
15/78
