Callout Number Ref. Des.
12 J407
13 J400,
J401
24 J395,
J396
25 J398,
J397
Switches
The following table lists the default switch settings.
Table: Default Switch Settings
Callout Number Ref. Des.
14 SW1
15 SW2
16 SW3
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Function
SYSCTLR JTAG mode
Default: QSPI32
Installed: JTAG
SFP RS0/1 input
1-2: Full BW RX
2-3: Low BW Rx
CAN0 termination option
CAN1 termination option
Function
U1 mode 4-pole DIP switch
Switch OFF = 1 = high; ON = 0 =
low
Mode = SW1[1:4] = Mode[0:3]
SD = ON,OFF,OFF,OFF = 0111
OSPI = ON,ON,ON,OFF = 0001
JTAG = ON,ON,ON,ON = 0000
VEK280 power-on reset (POR_B)
SYSCTLR JTAG source selection
Switch OFF = 1 = high; ON = 0 =
low
SYSCTLR JTAG SOURCE SEL =
SW3[1:2] = SEL[0:1]
PL JTAG = ON,ON = 00
FTDI JTAG = OFF,ON = 10
Unofficial Document
Default
DNP
Open
Installed
Installed
Default
ON, ON,
ON, ON
Open
OFF, ON
Schematic Page
77
29
41
41
Schematic Page
12
13
20
