Board Component Descriptions
The following table identifies the components and references the respective
schematic (038-05127-01) page numbers.
⚠ CAUTION!
board power connector J16. The ATX 6-pin connector has a different pinout than
J16. Connecting an ATX 6-pin connector into J16 damages the VEK280 board and
voids the board warranty.
Table: Board Component Locations
Callout No. Ref. Des.
1 U1
2 U317,
U318
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Do NOT plug a PC ATX power supply 6-pin connector into the VEK280
Feature
AMD Versal™
adaptive SoC
LPDDR4 16 GBIT
comp. memory
Unofficial Document
Notes
XCVE2802-2MSELSVC4072
1
The heatsink is not shown
in Figure 1
Micron
MT53E512M32D1ZW-046
Schematic Page
3-16
3,22,23
