Callout No. Ref. Des.
41 DS3,
DS4,
DS5,
DS6
42 J405
43 J331
44 U125
45 U301
46 U302
47 U304
48 U132
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
Feature
User LEDS
IEEE-1588 eCPRI
CLK in SMA
IEEE-1588 eCPRI
CLK out SMA
XCZU4EG system
controller
SYSCTLR
clock156.25 MHz
HSDP REFCLK
SYSCTLR clock
33.33 MHz
REFCLK
SYSCTLR clock 26
MHz USB REFCLK
System controller
LPDDR4 16 GBIT
comp. memory
Unofficial Document
Notes
Lumex SML-LX0603GW-TR
LED green
Rosenberger 32K10K-
400L5
Conn. rcpt. SMA vert. 50R
12.4 GHz
Rosenberger 32K10K-
400L5
Conn. rcpt. SMA vert. 50R
12.4 GHz
AMD XCZU4EG-2SFVC784E
AMD Zynq™ UltraScale+™
MPSoC
CTS 626L15625I3T
Osc 156.25 MHz 3.3V 25
PPM LVDS with OE
Renesas
XUJ716033.333333I
Osc 33.333333 MHz 1.8V
25 PPM LVCMOS with OE
Raltron XCO583IV11-
26.000
Osc 26 MHz 3.3V 30 PPM
LVDS with OE
Micron
MT53E512M32D1ZW-046
WT:D
IC SDRAM LPDDR4 16 Gb
512Mx32 2133 MHz
Schematic Page
48
92
92
73-83
89
89
89
86
