3/20/24, 12:51 PM
Attach a wrist strap to an unpainted metal surface of your hardware to prevent
electrostatic discharge from damaging your hardware.
When you are using a wrist strap, follow all electrical safety procedures. A
wrist strap is for static control. It does not increase or decrease your risk of
receiving electric shock when you are using or working on electrical
equipment.
If you do not have a wrist strap, before you remove the product from ESD
packaging and installing or replacing hardware, touch an unpainted metal
surface of the system for a minimum of five seconds.
Do not remove the device from the antistatic bag until you are ready to install
the device in the system.
With the device still in its antistatic bag, touch it to the metal frame of the
system.
Grasp cards and boards by the edges. Avoid touching the components and
gold connectors on the adapter.
If you need to lay the device down while it is out of the antistatic bag, lay it on
the antistatic bag. Before you pick it up again, touch the antistatic bag and the
metal frame of the system at the same time.
Handle the devices carefully to prevent permanent damage.
Board Component Location
The following figure shows the VEK280 board component locations. Each
numbered component shown in the figure is keyed to the table in
Descriptions.
Important:
‼
the current revision of the board.
Important:
‼
concerning the differences between revisions are not captured in this document.
This document is not intended to be a reference design guide and the information
herein should not be used as such. Always refer to the schematic, layout, and XDC
files of the specific VEK280 version of interest for such details.
Figure: Evaluation Board Component Locations
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
The following figure is for visual reference only and might not reflect
There could be multiple revisions of this board. The specific details
Unofficial Document
Board Component
10/78
