Table 27. Dataitem Keywords for Cmm Location (Sheet 4 of 7)
dataitem
Used to set or query SNMP
snmpenable
trap enabled status.
Get or Set the machine's IP
address that will receive
SNMP traps from a location.
Up to five addresses can be
set. Default is 0.0.0.0 for all 5.
snmptrapaddress[1-5]
Example:
cmmset -l cmm -d
snmptrapaddress3 -v
10.10.241.105
Get or Set the SNMP trap
community name.
Example:
cmmget -l cmm -d
snmptrapcommunity
snmptrapcommunity
Returns:
SNMP trap community:
publiccmm
Get or Set the TCP/IP port that
snmptrapport the SNMP trap will be sent to.
The default is 162.
Retrieves or sets SNMP trap
snmptrapversion
version. This is either v1 or v3.
Returns the uppercritical limit.
Note: It uses the sensor to
display the runtime value in
days since the last reset.
To retrieve the
airfilterruntimelimit
uppernoncritical limit use the
command:
cmmget -t "filter run time" -d
uppernoncritical
(or -d thresholdsall)
Resets the air filter runtime to
0. The set is supported to
resetairfilterruntime allow the user to set the run
time to zero when the filter is
replaced.
MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Get/
Description
Set
Both
Both
Both
Both
Both
Both
Set
The Command Line Interface (CLI)
CLI Get Output
SNMP traps are <enabled/disabled>.
"SNMP trap address: IpAddress"
where IpAddress is of the format
A.B.C.D
"SNMP trap community:
communityValue"
"SNMP trap port: portNumber"
"SNMP trap version: v1/v3"
<uppercritical limit> Days
N/A
Valid Set Values
1=Enable
0=Disable
enable
disable
<IpAddress>
Where:
<IpAddress> is a
Valid IP address in
the form: A.B.C.D
<CommunityName
>
Where
<CommunityName
> is any Valid
SNMP community
name 64 characters
or less. Ex:
publiccmm
Valid port number
0-65535
"v1" or "v3"
1. Disable eventing
on air filter run time
-v 0
2. Enable eventing
on air filter and set
the uppercritical
limit to (xxx) days,
and it also sets the
upper non-critical
value to 90% of the
uppercritical.
-v xxx
3. Enable eventing
on air filter and set
the uppercritical
limit to (xxx) days
and the upper non-
critical to (yyy) days
-v xxx,yyy
xxx and yyy must
be an integer
between 1 and 255.
1 - Only accepts a
value of 1
