FRU Update Configuration File
Table 103. Multi-Record Selection Parameters
Parameter
Number
1
2
3
4
5
6
NOTE:
1. Not allowed for the REMOVE operation.
The destination and source record IDs are based on the second parameter, the selector type. If the
selector type is 'RECORD ID' the utility should look at the OEM record ID in the record header. If
the selector type is 'PICMG ID' the utility should validate that the record is a PICMG record and
then compare to the PICMG record ID field. When multiple IDs match the selector ID, it is
necessary to be able to select each record; this can be done with the record count parameter. The
record count parameter indicates which number of the record that matched should be selected, 1 is
the first record discovered in the area. If the utility cannot find a record that matches the ID and
count of the selectors, it shall exit with an error and not perform any updates to the FRU.
Example:
FRUNAME SYSTEM
FRUADDRESS CHASSIS
FRUAREA MULTIREC REPLACE PICMG_ID 0x12 1 0x12 1
FRUAREA MULTIREC REMOVE RECORD_ID 0xC1 1
27.8.5

FRUFIELD

The FRUFIELD command must be preceded by a FRUAREA command. This command specifies
what and where the input value for this field is to come from when updating the FRU. If the same
field definition occurs multiple times in an area, then the modification made by the last field
definition will be the one used, and no error will be displayed to the user. Also, the field must exist
in the system FRU that is to be updated, the configuration file is only capable of modifying existing
FRU fields not adding new fields. The valid field selections for an area are listed in
below. The table below lists the description of the abbreviated field name and (the FRUFIELDs
that the field is allowed in).
236 MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Parameter Value
APPEND, INSERT, REMOVE,
REPLACE
"PICMG_ID", "RECORD_ID"
Number
Number
Number
Number
Description
Operation to perform for the selected record.
Method to use for selecting the source and destination
records.
Destination record ID to be selected.
Destination record count to be selected, 1 is the first record.
Source record ID to be selected.
Source record count to be selected, 1 is the first record.
1
1
Table 104
