Health Events
•
Timestamp is in the format:
Thu Dec 11 22:20:03 2003
•
ChassisLocation is the chassis location information recorded in the chassis FRU.
•
ChassisSN is the chassis serial number records in the chassis FRU.
•
Location is the location where the sensor generating the event is located (i.e., CMM)
•
SDR Sensor Name is the name given to the sensor in the Sensor Data Record (SDR).
•
Health Event Strings are listed in
page 108.
•
Event Type is either "Assertion Event" or "Deassertion Event" stating whether it is an event
that is being asserted or one that is being deasserted. This is not applied to threshold-based
sensor events since the string already states event type.
•
Event Code is a code unique to that event. The codes for each event can be found below in
Table 11.4, "List of Possible Health Event Strings" on page
11.2

Sensor Targets

Available sensors for a location can be retrieved with the listtargets dataitem argument of the
cmmget command. To view a list of sensor targets on the cmm using the listtargets command:
cmmget -l cmm -d listtargets
List of targets for the CMM can be found in
page 174.
For complete lists of sensors on other components (i.e., voltage sensors on blade1), refer to the
corresponding Technical Product Specification for that product.
Table 33. Sensor Targets (Sheet 1 of 2)
Sensor Target
Brd Temp
CPU Temp
FilterTrayTemp [1/2]
CPU Core V
VBAT
VTT DDR
+2.5V
+3.3V
+5V
+12V
CDM [1/2]
106 MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
[Day] [Month] [Date] [HH:MM:SS] [Year]. For example,
Section 11.4, "List of Possible Health Event Strings" on
Table 19, "Remote Procedure Calls (RPC)" on
Description
Board Temperature Sensor
CPU Temperature Sensor
Filter Tray Temperature Sensor
CPU Core Voltage Sensor
Battery Sensor
VTT Sensor
+2.5 Volt Sensor
+3.3 Volt Sensor
+5 V olt Sensor
+12 Volt Sensor
CDM 1 or 2 Sensor
108.
