11.4.2

CMM Location

Table 39. CMM Redundancy
"Regained"
"Established"
"Lost due to switch failure"
"Lost due to unhealthy signal"
"Lost due to CMM removal"
"Lost due to CMM reboot or halt"
"Lost due to critical event on the CMM"
"Lost due to inability to communicate with the other CMM over its
management bus."
"Lost due to incompatible firmware versions on the CMMs.
Please upgrade the CMMs to the same version."
Table 40. CMM Trap Connectivity (CMM [1-2] Trap Conn)
"Regained"
"Lost due to failed network connectivity between the CMM and
the Primary SNMP trap destination (SNMPTrapAddress1)."
Table 41. CMM Failover (Sheet 1 of 2)
"Failover occurred."
"Failover occurred because of switch failure."
"Failover occurred because of failed network connectivity
between the CMM and the Primary SNMP trap destination."
"Failover occurred because of critical CMM health events."
"Failover occurred because of a bad hardware signal from the
other CMM."
"Failover occurred because it was forced by the user."
"Failover cannot occur because the other CMM has a bad
switch."
"Failover cannot occur because the other CMM has lost network
connectivity with its Primary SNMP trap destination."
"Failover cannot occur because the other CMM has critical
health events."
MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Event String
Event String
Event String
Health Events
Event Code
Event Severity
Hex Decimal
0x0D0 208 OK
0x0D1 209 OK
0x0D2 210 Major
0x0D3 211 Major
0x0D5 213 Major
0x0D6 214 Major
0x0D7 215 Major
0x0D8 216 Major
0x0EF 239 Major
Event Code
Event Severity
0x0D0 208 OK
0x0D4 212 Major
Event Code
Event Severity
Hex Decimal
0x0D9 217 OK
0x0DA 218 OK
0x0DB 219 OK
0x0DC 220 OK
0x0DD 221 OK
0x0DE 222 OK
0x0E0 224 OK
0x0E1 225 OK
0x0E2 226 OK
