Cmm Targets - Intel NetStructure MPCMM0001 Software Instructions

The following table shows the values target can be for the CMM location.
Table 22. CMM Targets
Keyword
Brd Temp
CPU Temp
FilterTrayTemp[1,2]
CPU Core V
VBAT
VTT DDR
+2.5V
+3.3V
+5V
+12V
CDM [1,2]
Air Filter
Filter Tray
Filter Run Time
BIST
FRU Hot Swap
Filter Tray HS
IPMB-0 Snsr [1-16]
FRU
all_leds
hsled
userled[1-4]
feedN
PmsGlobal
PmsProcN
Datasync Status
CMM Status
PmsPieN
None
MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Description
Board Temperature
CPU Temperature
Filter Tray Temperature Sensors
CPU Core Voltage
Battery Voltage
CMM Memory voltage
+2.5V voltage sensor
+3.3V voltage sensor
+5V voltage sensor
+12V voltage sensor
Chassis Data Modules 1 and 2
Air Filter
Filter Tray FRU
Filter Run Time
Built-In Self Test Sensor
FRU Hot Swap sensor
Filter Tray Hot Swap sensor
IPMB 0 sensors
FRU file for CMM
Target for configuring all user-definable LEDs on the CMM front panel
Hot swap LED on the CMM front panel
Corresponds to userled A-D on the CMM front panel
Corresponds to power feed (i.e. feed1, feed2). Use the feedcount
dataitem to determine number of power feeds for component.
Target for PMS global data
Target for each process monitored where N is the process number
Datasync Status Sensor
CMM Status Sensor
Process monitoring process integrity sensors
Same as not entering a target
The Command Line Interface (CLI)
