SNMP
Table 61. Shelf Location (Equivalent to Chassis) (1.3.6.1.4.1.343.2.14.2.10.2)
OID
1 shelfListTargets
2 shelfListDataItems
3 shelfFanSpeed
4 shelfLocation
5 shelfHealth
6 shelfHealthEvents
7 shelfIPMICommandRequest
8 shelfIPMICommandResponse
1
Table 62. ShelfTable/shelfEntry (1.3.6.1.4.1.343.2.14.2.10.2.50.1) (Sheet 1 of 2)
OID
1 shelfTarget
23 shelfMinorAction
24 shelfMajorAction
25 shelfCriticalAction
26 shelfNormalAction
27 shelffruBoardDescription
28 shelffruBoardManufacturer
29 shelffruBoardPartNumber
30 shelffruBoardSerialNumber
144 MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Object Syntax
DisplayString
DisplayString
DisplayString
DisplayString
INTEGER
DisplayString
DisplayString
DisplayString
Object Syntax
OCTET
STRING
DisplayString
DisplayString
OCTET
STRING
OCTET
STRING
DisplayString
DisplayString
DisplayString
DisplayString
Access Value
Used to find out what targets are
read-only available on a location. (e.g., Getting
the list of sensors in the chassis).
Used to find out what data items are
read-only
available on a target or location.
Used to get or set the fan speed in the
chassis. Percent of the maximum fan
read-write speed that the chassis supports. Values
can be multiples of 10 from 20 to 100,
or 0xFE for emergency shutdown.
This is used to get or set the Location
field in the chassis FRU and is sent out
read-write
as a part of SNMP and UDP alerts. This
is only used with the chassis location.
Health information about a particular
Location. This will be one of the
read-only
following: (0-OK, 1-Minor, 2-Major, 3-
Critical).
Events that contribute to the Health of
read-only the Location. This is a list of events
happening on the Location.
Used to send any IPMI command to
read-write
this location.
Used to read the response to the above
read-only
IPMI command.
Access Value
none index
Used to configure user defined actions
write-only
when minor events occur.
Used to configure user defined actions
write-only
when major events occur.
Used to configure user defined actions
write-only
when critical events occur.
Used to configure user defined actions
write-only
when normal events occur.
Used to read the Board Description
read-only
from the FRU.
Used to read the Board Manufacturer
read-only
from the FRU.
Used to read the Board Part Number
read-only
from the FRU.
Used to read the Board Serial Number
read-only
from the FRU.
