Table 107 defines the valid types that can be used as the 'TYPE' option in FRU field 2
specifications. The load utility is not required to support all of these types.
Table 107. Type Code Specification
Type
ASCII
ASCII6
BCD
BIN
UNICODE
It's a lot to take in, so here are a few examples, you can also look at the example file at the end of
this document.
Example:
FRUNAME "MPCHC001.FRU"
FRUADDRESS CHASSIS
FRUAREA CHASSIS
FRUFIELD S# // gets the value from the MPCHC001.FRU file
FRUAREA BOARD
FRUFIELD MN "Intel" // puts 'Intel' in the field
FRUFIELD S# "@stdin:ascii" // user types in the value
FRUAREA PRODUCT
// Gets the value from an environment variable "prod_ser_num".
FRUFIELD S# "@env:ascii:prod_ser_num"
// Gets the value from the 4
FRUFIELD P# "@file:ascii:file_name:4"
MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Description
Straight 8 bit ASCII
6 bit ASCII packed bytes
Binary Coded Decimal.
Binary bytes
Note: Binary data will be displayed in
HEX format.
Unicode
th
line of the ASCII file 'file_name'.
FRU Update Configuration File
nd
FRUSDR Version
Ver 2.0 and later
Not supported
Ver 2.0 and later. Support for BCD only
exists when using Stdin and in the
original FRU file.
Not supported
Not supported
string
