Table 71. Blade#FruTargetTable/blade#FruTargetEntry (1.3.6.1.4.1.343.2.14.2.10.4.[1-16].53.1)
OID
1 b#FruNumber
2 b#Target
3 b#FruLedColorProps
4 b#FruLedState
Table 72. [FanTray/pem]Table/[fanTray/pem]Entry (1.3.6.1.4.1.343.2.14.2.10.[5/6].51.1)
OID
1 [fanTray/pem]Number
2 [fanTray/pem]FRUExtractionNotify
3 [fantray/pem]TotalFrus
4 [fanTray/pem]PICMGProperties
5 [fanTray/pem]DeviceID
6 [fanTray/pem]Presence
7 [fanTray/pem]ListTargets
8 [fanTray/pem]ListDataItems
9 [fanTray/pem]Health
10 [fanTray/pem]HealthEvents
[fanTray/
11
pem]IPMICommandRequest
[fanTray/
12
pem]IPMICommandResponse
13 fanTrayMinorLevel
14 fanTrayNormalLevel
15 fanTrayControl
16 fanTrayDefaultControl
17 fanTrayRestoreDefaults
18 fanTrayMinimumSetting
