Ipmb Slave Addresses; Cmm Rmcp Configuration - Intel NetStructure MPCMM0001 Software Instructions

20.7

IPMB Slave Addresses

In the current RMCP server implementation in the BMC, embedded 'IPMI message' within a
RMCP message is bundled with IPMB protocol. The 'slave address' required by this protocol
should be set to 20h to address the BMC. The RMCP client may use any of the address shown in
the range specified below as its slave Address. Only EVEN values are allowed. i.e., the least
significant bit of the slave address is always '0'.
Table 88. RMCP Slave Addresses
Nodes
RMCP Server Slave Address
RMCP Client Slave Address
20.8

CMM RMCP Configuration

To communicate with the CMM RMCP server a RMCP client must have the following
information:
•
the RMCP server's IP address
•
the User Name, which is initially set to root
•
the User Password, which is initially set to cmmrootpass
•
and set the RMCP mode to "Full Access"
All of these were discussed in the CLI section above.
MPCMM0001 Chassis Management Module Software Technical Product Specification
Download from Www.Somanuals.com. All Manuals Search And Download.
Value
20h
C0h-CEh
RMCP
193
