Chapter 2: Jumpers and Connectors
SATA Power Connector
Connector type: WtoB Con. 1x 2-pin header, 2.5mm
Connector location: SATA_PWR1
1
2
Pin
Definition
1
+5V
2
GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Speaker Connector
Connector type: 1x 4-pin header, 1.25mm pitch
Connector location: SPK
1
4
Pin
Definition
1
L_OUT+
3
R_OUT+
23
Pin
Definition
2
L_OUT-
4
R_OUT-
Neu-X102 User Manual
