Chapter 1: Product Introduction

Hardware Specifications

CPU Support
▪ Intel
Alder Lake-N processor, N50 (up to 3.4 GHz, 6W)
®
▪ Intel
Alder Lake-N processor, N97 (up to 3.6 GHz, 12W)
®
Graphics
▪ Intel
UHD Graphics
®
Main Memory
▪ 1 x 260-pin DDR4 SO-DIMM socket, up to 3200MHz with non-ECC,
un-buffered memory up to 16GB
I/O Interface-Front
▪ 2 x RJ45 with LEDs for 2.5GbE LAN
▪ 2 x HDMI 1.4b, 3840 x 2160 @ 30Hz
▪ 4x USB 3.2
▪ 1 Power button with LED
▪ 1 x DC-in jack with lock
I/O Interface-Rear
▪ 2 x Antenna holes
▪ 1 x COM port (RS232/RS422/RS485)
▪ 1 x Storage active LED
Internal I/O
▪ 1 x COM port connector (RS232, RI/5V/12V)
▪ 1 x Line-out audio connector
▪ 2 x (1 x 6P) Headers, for 3x USB 2.0 port
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Expansion
▪ 1 x Mini-PCIe full-size connector with SIM Slot (Nano), supports Wi-Fi/
LTE module
Storage
▪ 1 x M.2 M key 2242 for supporting SATA & PCIe signal
Power Supply
▪ 1 x External 60W AC/DC power adapter with lock
(power adapter is included)
▪ Input: 100VAC to 240VAC
▪ Output: DC+12VDC
Environment
▪ Operating temperature: -5°C to 50°C ambient with air flow
▪ Storage temperature: -20°C to 80°C
▪ Humidity: 95% (non-condensing)
▪ Shock protection: 50G peak acceleration, 11ms according to IEC60068-
2-27
▪ Vibration protection
- Random: 2Grms @ 5~500 Hz, IEC60068-2-64
- Sinusoidal: 2G @ 5~500 Hz, IEC60068-2-6
Certification
▪ CE (EMC EN55035 + EN55032)
▪ FCC Class A (EMI Part 15B)
▪ LVD (EN62368-1)
