Chapter 2: Jumpers and Connectors

USB2.0 Connector

Connector type: 1x 6-pin header, 1.0mm for 2x USB 2.0 port
Connector location: USB2_57
1 6
Pin Definition
1 GND
3 USB5P
5 USB7P
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 USB5N
4 USB7N
6 +5V
USB2.0 Connector
Connector type: 1x 6-pin header, 1.0mm for 1x USB 2.0 port
Connector location: USB2_3P
1 6
Pin Definition
1 GND
3 NC
5 USB3P
24
Pin Definition
2 NC
4 USB3N
6 +5V
