Chapter 2: Jumpers and Connectors
eDP Definition
Pin Definition
1 N.C.
3 EDP_TX0P
5 EDP_TX1P
7 EDP_HPD
9 N.C.
11 N.C.
13 N.C.
15 N.C.
17 GND
19 +V_PANEL
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 N.C.
4 EDP_TX0N
6 EDP_TX1N
8 N.C.
10 N.C.
12 N.C.
14 N.C.
16 N.C.
18 +V_PANEL
20 +V_PANEL
Pin Definition
21 GND
23 GND
25 GND
27 EDP_AUXN
29 GND
31 Hot-Plug Detect
33 INV_BKLTCTRL
35 N.C.
37 +V_INV
39 +V_INV
18
eDP Definition
Pin Definition
22 +V_PANEL
24 GND
26 EDP_AUXP
28 GND
30 GND
32 INV_BKLTEN
34 N.C.
36 +V_INV
38 +V_INV
40 GND
