Specifications, cont'd
Return loss
P/2 DA2 Plus ................... -38.3dB @ 5 MHz
P/2 DA4/DA6 Plus ......... -45dB @ 5 MHz
Video output
Number/signal type
P/2 DA2 Plus ................... 2 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
P/2 DA4 Plus ................... 4 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
P/2 DA6 Plus ................... 6 VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... 2, 4, or 6 15-pin HD female (depending on the
model)
Nominal level ............................... 0.7V p-p (excluding sync)
Minimum/maximum levels
P/2 DA2 Plus ................... 0.4V to 1.4V p-p
P/2 DA4/DA6 Plus ......... 0.3V to 1.5V p-p
Impedance .................................... 75 ohms
Return loss
P/2 DA2 Plus ................... -41dB @ 5 MHz
P/2 DA4/DA6 Plus ......... -45dB @ 5 MHz
DC offset ....................................... ±5mV maximum with input at 0 offset
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... 3.0V to 5.0V p-p
Output level .................................. TTL ............. 5V p-p
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Max. propagation delay .............. 60 ns
Max. rise/fall time
P/2 DA2 Plus ................... 4 ns
P/2 DA4/DA6 Plus ......... 2 ns
Polarity .......................................... Positive or negative
General
Power
P/2 DA2 Plus ................... 100VAC to 240VAC, 50/60 Hz, 4.5 watts,
external, auto-switchable; to 9VDC, 1 A power
supply.
P/2 DA4/DA6 Plus ......... 100VAC to 240VAC, 50/60 Hz, 12 watts, internal,
auto-switchable
4 P/2 DA 2/4/6 Plus • Specifications
Specifications, cont'd
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to
90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to
90%, non-condensing
Rack mount
P/2 DA2 Plus ................... No
P/2 DA4/DA6 Plus ......... Yes, with optional 1U rack shelf, part #60-190-01
Enclosure type
P/2 DA2 Plus ................... Plastic
P/2 DA4/DA6 Plus ......... Metal
Enclosure dimensions
P/2 DA2 Plus ................... 1.4" H x 5.0" W x 3.3" D
3.6 cm H x 12.7 cm W x 8.4 cm D
(Depth excludes connectors.)
P/2 DA4/DA6 Plus ......... 1.6" H x 8.75" W x 9.4" D (1U high, half rack
width)
4.1 cm H x 22.2 cm W x 23.9 cm D
(Depth excludes connectors.)
Product weight
P/2 DA2 Plus ................... 1.6 lbs (0.7 kg)
P/2 DA4/DA6 Plus ......... 2.2 lbs (1.0 kg)
Shipping weight
P/2 DA2 Plus ................... 3 lbs (1.4 kg)
P/2 DA4 Plus ................... 4 lbs (1.8 kg)
P/2 DA6 Plus ................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
