Reference

Reference

:DIGital[1|2|3|4]:PATTern:LENGth

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

:DIGital[1|2|3|4]:PATTern:TYPE

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
32
Set & Query
Numeric
None
None
8
Programs the Pattern Length. This value is only relevant if the pattern type is DATA.
For the one channel instruments, the length may be any integer from 2 through 4,194,304. In a
two or four channel unit, the maximum pattern length per channel is 2,097,152.
Set Ch1 pattern length to 56
:DIG1:PATT:LENG 56
Set Ch2 pattern length to 500
:DIG2:PATT:LENG 500
Query Ch 1 pattern length
:DIG1:PATT:LENG?
Set & Query
DATA | PRBS
None
None
PRBS
Programs the Pattern Type.
Set the Ch 1 pattern type to PRBS
:DIG1:PATT:TYPE PRBS
Query Ch 1 pattern type
:DIG1:PATT:TYPE?
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
