Functional verification

Power on and verify instrument operation

8
The following steps assume the unit is connected as shown in the verification
setup.
NOTE.
Note: The generator is internally temperature compensated for timing and
output level continuously and automatically. Internal timing calibration will also
take place whenever the frequency is set (either manually or through remote
programming). Setting the frequency (or resetting the frequency to its current
value) is recommended after an initial 15-minute warm-up, or if a significant
change in ambient temperature has occurred during operation.
1. Push front panel on/off switch.
The green light on the switch turns on.
The instrument goes through the start-up sequence.
The Main menu displays on the touch screen.
2. Select UTILITY by touching the on-screen button.
3. Select SAVE.
4. Select RECALL DEFAULTS (The instrument loads all the default settings.)
5. Select BACK.
6. Select MAIN.
7. Turn OUTPUT ON.
8. Use the AUTO SCALE function on the sampling oscilloscope to identify and
display signals.
9. Adjust the sampling oscilloscope voltage, timing and display settings as
needed.
Channel 1 shows PRBS data with pattern trigger.
Channel 2 shows a square wave at the default clock rate.
The output should be similar to the following figure (the displayed data
pattern may differ).
