Preface

Features

PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
The Tektronix PatternPro line of high-performance pattern generators offer single
and multi-channel configurations capable of data rates up to 32 Gb/s. With
optional jitter insertion, the PPG line offers a flexible, cost effective and easy to
use test solution supporting high speed applications such as 100 Gigabit Ethernet,
32G Fibre channel, PAM4, DP-QPSK testing, and a broad range of receiver
test applications. The single unit multi-channel configurations provide aligned,
pattern-independent data outputs that support testing of crosstalk immunity and
multi-channel functionality. The PPG line can be paired with the Tektronix PED
line of Error Detector products to provide a complete BER test capability.
The data rate can be programmed over a broad range of values. The output may
be either built-in PRBS patterns or programmed user data patterns.
The PPG pattern generators series provide the following features:
1.5 Gb/s to 16 Gb/s operation (PPG1600 series)
1.5 Gb/s to 30 Gb/s operation (PPG3000 series)
1.5 Gb/s to 32 Gb/s operation (PPG3200 series)
Fully integrated benchtop instruments
Available with 1, 2, or 4 output channels
Independent data on channels
Independent channel skew adjustment
Independent channel pattern bit shift
Adjustable data amplitude and offset (PPG1600 and PPG3000 series)
250 mV to 2 V single ended (500 mV to 4 V differential)
-2 V to 3 V window
Fast rise/fall time (PPG3200 series)
300 mV to 1 V single ended adjustable; 600 mV to 2 V differential
User programmable data or built-in PRBS patterns
Adjustable internal clock source
Full rate
10 kb/s resolution
Selectable prescaler output
