Preface
x
External clock input
Trigger output
programmable as pattern trigger or clock/n
Jitter insertion (option):
High Frequency SJ/RJ/BUJ jitter insertion (Option HFJIT)
Low frequency jitter insertion (Option LFJIT)
External modulation input
Save up to twenty-five user patterns in nonvolatile memory
Save up to twenty-five generator setups in nonvolatile memory
Touch screen graphical user interface & USB TMC interfaces
3RU height, full-rack design for 1-channel or 2-channel unit
6RU height, full rack design for 4-channel unit

Table i: Product description

Instrument
PPG1601
PPG1602
PPG1604
PPG3001
PPG3002
PPG3004
PPG3201
PPG3202
PPG3204
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Maximum data rate
16 Gb/s
16 Gb/s
16 Gb/s
30 Gb/s
30 Gb/s
30 Gb/s
32 Gb/s
32 Gb/s
32 Gb/s
Differential channels
1
2
4
1
2
4
1
2
4
