Sense:roscillator:source; [:Source]:Frequency[:Cw|:Fixed]; [:Source]:Skew[1|2|3|4] - Tektronix PatternPro PPG1600 User Manual

:SENSe:ROSCillator:SOURce

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:FREQuency[:CW|:FIXed]

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:SKEW[1|2|3|4]

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Set & Query
INTernal | EXTernal
None
None
INT
Programs the 10 MHz reference source.
Set the 10 MHz reference source to use the internal reference.
:SENSE:ROSCILLATOR:SOURCE INTERNAL
Set & Query
Numeric [Hz]
None
None
16e9 for PPG1600 series
30e9 for PPG3000 series
32e9 for PPG3200 series
Programs the internal clock frequency, and also selects the internal clock as clock source if
it is not already selected.
Set frequency to 28 GHz.
:FREQ 28e9
Set & Query
Numeric [ps]
None
None
0 ps
Programs the skew.
Set the channel 1 skew to 20 ps.
:SKEW 20e-12
Reference
43
