[:SOURce]:PM[1|2|3|4][:HF]:INTernal4:FREQuency

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:PM[1|2|3|4][:HF]:INTernal4:PLENgth

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:PM[1|2|3|4][:HF]:INTernal4:STATe

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Set & Query
Numeric [Hz]
None
None
2 GHz
Programs the clock frequency of the PRBS used to generate the BUJ jitter. Units are Hz.
Set clock frequency of the channel 1 BUJ PRBS to 1.7 GHz.
:PM1:INT4:FREQ 1.7GHz
Set & Query
7 | 9 | 11 | 15 | 23 | 31
None
None
31
Programs the length of the PRBS used to generate the BUJ jitter. PRBS Length is specified as
2 -1, where N is the specified value.
N
Set PRBS Length of the channel 2 BUJ PRBS to (2
:PM2:INT4:PLEN 15
Set & Query
OFF | ON
None
None
OFF
Programs the channel internal BUJ jitter source enable/disable status. Both this setting and
[:SOURce]:PM[1|2|3|4][:HF][:STATe] for a given channel must be on for BUJ jitter to be applied.
Disable the channel 1 internal BUJ jitter source.
:PM1:INTERNAL4:STATE OFF
-1).
15
