:MMEMory:LOAD:STATe

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

:MMEMory:MOVE:PDATa

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

:MMEMory:MOVE:STATe

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Set
String
None
None
N/A
Recalls the instrument setting from a saved file in system memory. Every parameter of the
instrument is recalled except for pattern data, pattern length and output enable status. The
filename can be up to 8 characters long and is not case-sensitive. Filenames must consist
of only alphanumeric characters.
Recall the instrument settings from file "PARAM22".
:MMEM:LOAD:STAT "PARAM22"
Set
String
None
None
N/A
Rename the existing saved pattern data file in system memory. The filename can be up to
8 characters long and is not case-sensitive. Filenames must consist of only alphanumeric
characters.
Rename the pattern data file PATT1011 to PATT0101.
:MMEM:MOVE:PDAT "PATT1011", "PATT0101"
Set
String
None
None
N/A
Rename the existing saved instrument settings file in system memory. The filename can be up
to 8 characters long and is not case-sensitive. Filenames must consist of only alphanumeric
characters.
Rename the instrument settings file PARAM22 to PARAM.
:MMEM:MOVE:STAT "PARAM22", "PARAM"
Reference
39
