Reference

[:SOURce]:PM[1|2|3|4][:HF]:INTernal4:CALibration

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:PM[1|2|3|4][:HF]:INTernal4[:DEViation]

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:PM[1|2|3|4][:HF]:INTernal4:FILTer

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
46
Set & Query
GAUSsian | CEI
None
None
GAUS
Programs the calibration source for the BUJ amplitude. BUJ amplitude is calibrated under
two conditions; select the source closest to the current settings. The settings for each cal
are given below.
Frequency
Gaussian 2 Gb/s
CIE 1.1 Gb/s
Select the CEI calibration for channel 2.
:PM2:INTERNAL4:CAL CEI
Set & Query
Numeric [S]
None
None
0 ps
Programs the peak-to-peak amplitude of the channel internal BUJ jitter source. Units are
Seconds.
Set the channel 1 internal BUJ random jitter source to 12 ps peak-to-peak.
:PM1:INT4 12ps
Set & Query
Numeric [Hz]
None
None
100 MHz
Programs the bandwidth of the low-pass filter used to generate the BUJ jitter. Units are Hz.
Valid values are 25 MHz, 50 MHz, or 100 MHz. Other values will be rounded to the nearest
valid value.
Set the channel 3 internal BUJ low-pass filter to 50 MHz.
:PM3:HF:INT4:FILTER 50MHz
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Filter Plength
100 MHz 31
100 MHz 7
