Input and output descriptions
Functional block diagram
Data outputs
Output range
12
The basic functional blocks are shown in the following figure.
Figure 6: Block diagram
The instrument is designed to drive a 50 Ω load. The voltage window is adjustable
over the range from -2 V to +3 V.
WARNING.
To ensure proper operation, never load the output with less than 50 Ω.
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
