Built-in random noise
source
Built-in BUJ source
External modulation input
Low frequency jitter
insertion (Option LFJIT)
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Programmable from either the front panel touch screen or remote control.
Amplitude range. 0 to 5 ps
Accuracy. ±10% typical
Programmable from either the front panel touch screen or remote control.
Amplitude range. 0 to 50 ps
Modulation data rates. 100 Mb/s to 2.5 Gb/s
PRBS sequences. 7,9,11,15,23,31
Filter values. 25/50/100 MHz filters
DC coupled, 3 dB bandwidths
Frequency range. DC to 100 MHz
Amplitude range. 0 to 50 ps
Maximum input. 1 V
p-p
Add-on option.
The specifications below apply when the data rate equals the internal clock rate
frequency of 16 to 32 GHz. For each frequency octave below, the internal clock
rate, the specifications below will be reduced by half. Thus when the data rate is 8
to 15.99999 Gb/s, the values below will be divided by 2. When the data rate is
4 to 7.99999 Gb/s, the values will be divided by 4.

Table 5: SJ modulation range curve points

Parameter
10 Hz f
mod
100 Hz f
mod
1 kHz f
mod
10 kHz f
mod
100 kHz f
mod
1 MHz f
mod
2 MHz f
mod
10 MHz f
mod
RMS
p-p
p-p
Value
5000 UI
p-p
2000 UI
p-p
2000 UI
p-p
2000 UI
p-p
100 UI
p-p
10 UI
p-p
1 UI
p-p
0.5 UI
p-p
Specifications
