Getting started
Power requirements
Ventilation
2
CAUTION.
Operating the instrument on an incorrect line voltage can cause
damage, possibly voiding the warranty. To avoid this, operate the instrument
with the correct line voltage.
The instrument operates from a single-phase line voltage listed in the following
table. Line voltage and line frequency are automatically sensed; there are no
switches to set. Check to ensure the operating voltage in your area is compatible.

Table 1: Power requirements

Item
Voltage
Frequency
Power
PPG1601, PPG1602, PPG3001, PPG3002,
PPG3201, PPG3202
PPG1604, PPG3004, PPG3204
Power fuse
PPG1601, PPG1602, PPG3001, PPG3002,
PPG3201, PPG3202
PPG1604, PPG3004, PPG3204
The power cord supplied with the instrument contains a separate ground for use
with grounded outlets. When proper connections are made, the instrument chassis
is connected to power line ground through the ground wire in the power cord
providing protection against electric shock.
The unit has four fans in the rear, as well as cooling vents on the bottom and
side panels to keep it from overheating.
CAUTION.
Inadequate ventilation can damage the instrument; to avoid damaging
the instrument, observe the following precautions:
Do not block the cooling vents.
Do not position any devices adjacent to the instrument that force air (heated or
unheated) into or onto the instrument surfaces or cooling vents. This additional
airflow could compromise performance.
