Reference

:OUTPut[1|2|3|4]:POLarity

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

:OUTPut[1|2|3|4][:STATe]

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

:OUTPut:CLOCk:DIVider

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example
42
Set & Query
NORMal | INVerted
None
None
NORMal
Programs the polarity of the channel outputs.
Set Ch 1 for inverted output
:OUTPUT1:POLARITY INV
Set & Query
OFF | ON
None
None
OFF
Programs the enable/disable status of the channel outputs.
Disable the Ch 1 output.
:OUTP1 OFF
Set & Query
1 | 2 | 4 | 8 | 16
None
None
Varies with model and options. The minimum allowed value is either 1 or 2.
Programs the clock output divider. The input to this divider is internal clock, and the output
from the divider goes to the clock output or to the divided clock output if the full rate and divided
outputs are separate. The maximum and minimum valid values depend on the instrument
model and options.
Program clock divider for 8.
:OUTP:CLOC:DIV 8
