Table 20: Marker outputs (cont.)
Characteristics
Type of output
ON/OFF Control
Output impedance
Output voltage
Amplitude range
Window
Resolution
External termination voltage
Maximum output current
DC accuracy (warranted)
Rise/fall time
Aberrations
Random jitter
Sample rate
Minimum pulse width
Maximum data rate
Skew between markers
(From the same channel)
Variable delay control
Range
Resolution
Accuracy

Table 21: 10 MHz Ref Out (reference output)

Characteristics
Connector type
Output impedance
Amplitude
Frequency (warranted)
16
Description
Single ended.
Independent control for each marker.
50 Ω
Independent control for each marker.
Output voltage into RLOAD [Ω] to GND is approximately (2 * RLOAD / (50 + RLOAD) ) times of
voltage setting.
0.2 V
to 1.75 V
into 50 Ω.
p-p
p-p
–0.5 V to 1.7 V into 50 Ω.
0.1 mV
–1.0 V to +3.5 V.
60 mA
±(10% of |output high or low setting| + 25 mV) into 50 Ω.
< 150 ps (20% to 80% of swing when High = 0.4 V, Low = –0.4 V).
< 20%
for the first 1 ns following the step transition with 100% reference at 10 ns.
p-p
5 ps
2.5 GS/s to 5 GS/s.
400 ps
2 Samples at 5 GS/s.
2.5 Gb/s.
Minimum pulse width does not support data output at maximum sample rate.
±25 ps
Independent control for each marker.
±2 ns
1 ps
±25 ps from delay value.
Description
SMA on rear panel.
50 Ω (AC coupled).
+4 dBm, ±2 dBm. Sine wave output.
Within ±(1 ppm + Aging), Aging: ±1 ppm per year.
(Temperature between 0 °C to 50 °C.)
AWG5200 Series Technical Reference
