[:SOURce]:VOLTage[1|2|3|4][:POS|:NEG][:LEVel][:IMMediate]:[:AMPLitude]

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:VOLTage[1|2|3|4][:POS|:NEG][:LEVel][:IMMediate]:OFFSet

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:VOLTage[1|2|3|4][:POS|:NEG][:LEVel][:IMMediate]:TERMination

Form
Parameters
Value Coupling
Range Coupling
Default
Description
Example

[:SOURce]:VOLTage[1|2|3|4][:LEVel][:IMMediate]:LINK

Form
Parameters
Value Coupling
PPG1600, PPG3000, & PPG3200 Pattern Generator User Manual
Set & Query
Numeric [V]
None
Offset
500 mV
Programs the amplitude of the output signal for the channel's positive or negative data outputs.
Set Ch 1 positive data amplitude to 1V.
:VOLT1:POS 1V
Set & Query
Numeric [V]
None
Amplitude
0 V
Programs the offset of the output signal for the channel's positive or negative data outputs.
Set Ch 1 negative data offset to –0.5V.
:VOLT1:NEG:OFFS –0.5V
Set & Query
Numeric [V]
None
Amplitude, Offset
0 V
Programs the user-supplied external termination voltage for the channel's positive or negative
data outputs.
Set Ch 1 positive term voltage to –1.0 V.
:VOLT1:POS:TERM –1.0V
Set & Query
None
None
Reference
