Appendix G – Power Supply 150 W Switch 110/230 VAC
The power supply of the BlueBox is via an external 24 V DC power supply.
If the power supply is factory
set to 110 – 120 V AC, there is a
sticker here.
Opening the housing
∗
As shown in Appendix F – Opening of a BlueBox Housing on the previous page.
GO Systemelektronik GmbH
The work described here may only be performed by trained
Determine the magnitude of the input voltage.
Overvoltage may result in damage.
∗
Disconnect the power supply from line voltage.
1. Remove the covers on both sides of the BlueBox.
2. Unscrew the four fixing screws.
3. Open the housing by lifting the cover from front to back top.
Faluner Weg 1 24109 Kiel
www.go-sys.de
specialist staff.
24 VDC cable 110/230 VAC cable
