B l u e B o x – M e n u O p e r a t i o n
8.2.1.1.5.1.1 Setting IP Address (UDP)
Menu UDP settings 8.2.1.1.5.1
IP-Address
Here you can enter the IP address of the destination computer in the Internet, to which the measuring data is
transmitted. The UDP protocol via port 14112 is used for the transmission. The current IP address is shown.
If an access to the BlueGate server was ordered, the IP address of the BlueBox is set to the default address
91.221.182.141 upon delivery.
Deletes the last entered character.
<
Saves the IP address.
Ok
Switches back to the menu UDP settings.
<–
3. BlueGate Settings:
IP Address
Password BlueGate
see 6 The Configuration Data Sheet
see also 8.2.1.1.5.2 Gateway Settings (Internet)
GO Systemelektronik GmbH
91.221.182.141
Ok
91.221.182.141
xxxxx
Faluner Weg 1
24109 Kiel
www.go-sys.de
1
2
3
4
5
6
7
8
9
.
0
<
<–
Germany
Tel.: +49 431 58080-0
info@go-sys.de
Page 46 / 99
Fax: -58080-11
