B l u e B o x – M e n u O p e r a t i o n

8.2.2.1.1 Interval and Average

Sensor menu 8.2.2.1
Inter val
Average
Interval: Period in seconds between the end of a measurement and the end of the next measurement.
Choose the interval according to the characteristics of the sensor. Each sensor requires a certain minimum
period for measuring a value.
Please note the data sheet of the sensor.
The higher the interval is set, the fewer measurements are taken, the shorter the download time.
Averaging: The measured value is the arithmetic average of the selected number of single measurements.
Inter val
Aktual value 60
Ok
Deletes the last entered character.
<
Saves the input and switches back to the Sensor menu.
Ok
Switches back to the Sensor menu without saving the input.
<–
GO Systemelektronik GmbH
1
2
3
4
5
6
7
8
9
<
0
<–
Current settings are displayed as "Actual value".
interval
measurement cycle
Faluner Weg 1
24109 Kiel
www.go-sys.de
Average
Aktual value 6
Ok
Germany
Tel.: +49 431 58080-0
info@go-sys.de
1
2
3
4
5
6
7
8
9
<
0
<–
single
new
measurements
measurement
(here 5)
measuring
time
Page 68 / 99
