B l u e B o x – M e n u O p e r a t i o n

8.2.2.1.6 Selection Calibration Mode

Sensor menu 8.2.2.1
Cal. mode
Here you can set the calibration mode of a sensor.
One point calib ration y0=0
One point calib ration y0=fix
Two point calib ration
<–
The values of the data points are the running average from the last 15 seconds
A detailed description of the calibration can be found in:
The calibration of the two optional current outputs only happens with the AMS software.
Strictly speaking, these are the last 15 measurement values, but since all connected sensors (in fact all but the ISA spectrome
ter) are automatically set to a measurement interval of one second during calibration, it's the running average of the last 15
seconds.
GO Systemelektronik GmbH
GO Systemelektronik recommends using the default setting.
One point calib ration
One point calib ration
Two point calib ration
Calibration mode one point calibration with a calibration curve
through the origin.
The button is also a status indicator.
Calibration mode one point calibration with a calibration curve
whose y0-value is set by the calibration factors of the
sensor.
The button is also a status indicator.
Calibration mode two point calibration
The button is also a status indicator.
Switches back to the Sensor menu.
Appendix B - Calibration of a pH Sensor
Appendix C - Calibration of an Oxygen Sensor
Faluner Weg 1
24109 Kiel
www.go-sys.de
y0=0
y0=fix
<–
Germany
Tel.: +49 431 58080-0
info@go-sys.de
.
Page 73 / 99
Fax: -58080-11
