B l u e B o x
7 Switching On the BlueBox and Password Input
After the Blue Box has been started by switching on the power supply, shortly thereafter the following notes
appear in succession on the display
During this time the BlueBox checks the database and initiates the system.
Faluner Weg 1 D-24109 Kiel +049-431-58080-0 WWW.GO-SYS.DE
Then the BlueBox initiates the connected sensors and actuators.
Boot Info
Sensors
Aktuators
Vir tual Sensors
Once the initialization is complete, the display shows the number of connected sensors, actuators and virtual
sensors
. After 20 seconds or after pressing > OK < the Parameter display (8.1) appears.
2
At delivery the touch panel is calibrated and ready for use. After a longer storage it may be necessary to adjust for the
1
touch panel (see Appendix A).
The setup of virtual sensors is done with the AMS software, see manual BlueBox PC Software.
2
GO Systemelektronik GmbH
.
1
GO
SYSTEMELEKTRONIK
09:19:39
10.07.10
Search
3 / 3
0 / 0
1 / 1
Menu
Faluner Weg 1
24109 Kiel
www.go-sys.de
Init
System
Boot Info
Ready
Sensors
Aktuators
Vir tual Sensors
Germany
Tel.: +49 431 58080-0
info@go-sys.de
Check
Filesystem
09:19:39
10.07.10
3 / 3
0 / 0
1 / 1
Ok
Page 31 / 99
