B l u e B o x – M e n u O p e r a t i o n

8.2.1.6 Display

System menu 8.2.1
Displ ay
Press a point on the bar for Light or Dark to set the value of the backlight of the display.
When there is no user activity, after 150 seconds the software turns the backlight of the display to the value of
Light to the value of Dark. If there is user activity it switches back.
At an elevated temperature of the CPU the Dark value is ignored and the backlight of the display is switched
off.
D ispla y with 8 sensors
Displ ay 6 sensors
Displ ay 1 sensor
Selected sensors
Sensors & actuators
Only sensors
<–
1
Appears only at a BlueBox with a colour display.
The status of an actuators can also be understood as a measurement value.
2
GO Systemelektronik GmbH
Display
Light
Dark
Displ ay 1 sensor
Selected sensors
Switches back and forth between the
• Parameter display 8-way
• Parameter display 6-way
• Parameter display single
see 8.1 Parameter display
The button is also a status indicator.
Defines which sensors/actuators
ple parameter display (see 8.1.2 Multiple parameter display).
The button is also a status indicator.
There are three possibilities:
• Only selected sensors and actuators are displayed. Selection
via 8.2.2.1 Measurement value menu/Sensor menu and 8.2.3.1
Actuator menu
• All sensors and all actuators are displayed.
• All sensors are displayed.
Switches back to the system menu.
