B l u e B o x

1.2 Technical Data BlueBox T4

Computer:
Display:
Storage media:
Mechanical data:
Power supply:
Interfaces:
Modem (optional):
Ambient conditions:
To ensure equipment protection and the proper functioning of the device, the above conditions are strictly to be
adhered to!
The connected modules receive their power from the BlueBox. Some modules have a constricted input range, so there is a
input voltage tolerance of ± 10%.
GO Systemelektronik GmbH
PC 104, 200 MHz to 500 MHz
Operation system: Embedded Linux®
Main memory 256 MB
Touchpanel 480 x 272 pixel; coloured
Industrial CompactFlash card
Housing dimensions:
Weight:
IP code (housing):
Die-cast aluminium housing, powder coated
Colour:
Nominal voltage:
Nominal power:
additionally max. 1.85 A via the output to the modules
additionally optional 12 VDC/6 W for a power supply at the serial interface connection
1 x CAN
2 x Relay output
1 x USB (not TS and TC)
1 x Ethernet 10 or 100 Mbit/s
1 x RS-232 or RS-485 (half-duplex) optional with 12 VDC power supply
2 x current output 4 mA – 20 mA
2 x Pulse-/Digital input
Modem HSPA or Modem ISDN/analogue
Ambient temperature:
Relative humidity:
Faluner Weg 1
24109 Kiel
www.go-sys.de
256 MB; 512 Mb; 2 GB
280 mm x 170 mm x 90 mm (W x L x H)
approx. 2.5 kg
IP65
RAL 5010
24 V DC (18 V – 28 V)
T4: 10 W; TS and TC: 13 W
contact load 48 V/0.5 A
switching current approx. 6 mA; measurement range
up to 20 kHz; debounced up to 100 Hz
Storage:
-10 °C to +50 °C
Operation:
-20 °C to +45 °C
avoid direct sunlight
≤ 90 % (annual average)
Germany
Tel.: +49 431 58080-0
info@go-sys.de
Article-No. 486 0004
Page 9 / 99
Fax: -58080-11
