B l u e B o x

3.3.2 Connector Pin Assignment at the BlueBox T4 Basic

3
4
1
2
4
3
4
1
3
2
1
GO Systemelektronik GmbH
Power supply 24 VDC
panel plug (M12, male)
3
+24 VDC
4
GND 24 V
CAN-bus
panel socket (M12, female)
1
CAN-H
2
CAN-L
3
+24 VDC
4
GND 24 V
RS-232 or RS-485
panel plug (M8, male)
RS-232
1
GND
3
RX
4
TX
Current output 4 – 20 mA
panel socket (M8, female)
1
+24 VDC
2
I-Return
Faluner Weg 1
24109 Kiel
www.go-sys.de
RS-485
GND
RX/TX-
RX/TX+
Germany
Tel.: +49 431 58080-0
info@go-sys.de
Current output 1 2
Page 18 / 99
Fax: -58080-11
