B l u e B o x – M e n u O p e r a t i o n

8.2.4.1 Actuator menu

Example Relay 1
Relay 1
From this menu you can turn on and off a connected actuator and represent his values over time and see the
current settings of the actuator. For the specific settings of the connected actuator, please refer to the descrip-
tion of the actuator.
Switches to the set menu of the actuator.
Set
Switches to the diagram display of the actuator behaviour.
Diag ram
Switches to the info menu of the actuator.
Info
Selects the actuator for the multiple parameter display or not.
Selected
see also 8.2.1.6 Display
Selected
Switches back to the Main menu.
<–
